Textron Jacobsen AR-5 Technical/Repair Manual

4-4 4181383 First Edition
ELECTRICAL
4
Specifications
Test and Adjustment Specifications
Specifications
Resistance Across Solenoid Coil—
Raise Solenoid Coil at 68°F
ohms 7.0 ± 10%
Resistance Across Solenoid Coil—
Lower Solenoid Coil at 68° F
ohms 6.0 ± 10%
Resistance Across Solenoid Coil—
Mow Solenoid Coil at 68° F
ohms 9.8 ± 10%
Fuel Level Sender Resistance
Between Terminals at Full Position
ohms Between 26 and 35
Fuel Level Sender Resistance
Between Terminals at Empty Position
ohms Between 211 and 286

Textron Jacobsen AR-5 Specifications

General

Brand	Textron
Model	Jacobsen AR-5
Category	Lawn Mower
Language	English
