Textron Jacobsen AR-5 Technical/Repair Manual

HYDRAULICS
4181383 First Edition 6-11
6
Steering Circuit Schematic
See Figure 6-7.
Figure 6-7
1 Operating-pressure Oil to Deck Valve (Port P1) 3 Operating-pressure Oil to Lift Valve (Port P)
2 Operating-pressure Oil to Deck Valve (Port P2)
TN1369
Operating Pressure Oil
Return Oil
Inlet or Drain Oil
1740 psi
Steering Unit
AUX
IN
OUT
LT
4.13 ci
1
Steering
Cylinder
RT
2
Gear Pump
0.88 ci
2850 ±50 RPM
0.88 ci
0.5 ci
3
Hydraulic
Oil Cooler
100
Mesh
Screen
25 psi
Crack
Bypass
Hydraulic
Oil Tank
25 psi
Crack
Bypass
Return Oil
Filter
10
Micron
