STEERING
4181383 First Edition 7-3
7
Component Location
See Figure 7-1.
Figure 7-1
1 Steering Unit Pump
2 Steering Column
3 Steering Tower
4 Tilt Bracket
5 Steering Valve
6 Steering Wheel
7 Steering Cylinder
8Tie Rod
9 Steering Axle
1
3
5
4
2
6
9
7
8
TN1443,1417,1389,1422
