Textron Jacobsen AR-5 Technical/Repair Manual

3-2 4181383 First Edition
ENGINE
3
Specifications
General Engine Specifications
Engine AR-5 Model 68080 and AR-522 Model 68082
Manufacturer/Model Kubota
®
V2003-M-T E2B
Engine Type 4-stroke, diesel
Fuel Requirement No. 2-D diesel fuel (Cetane Rating-45)
Number of Cylinders/Configuration 4, in-line
Displacement
cu in. (cc) 121.9 (1999)
Bore x Stroke
in. (mm) 3.27 x 3.64 (83 x 92.4)
Power Output
hp (kW) 55 (41.0) @ 2800 rpm
Firing Order 1-3-4-2
Compression Ratio 22:1
Injection Timing (Before T.D.C.) 18°
Cooling System liquid cooled
Cooling System Capacity
qt (L) 8 (7.6)
Idle Speed 950 rpm
Maximum Speed (No Load) 2850 rpm
Oil Sump Capacity
qt (L) 10 (9.5)
Alternator 12 volt, 40 amp
Dry Weight
lb (kg) 410 (186)
Engine AR-522 Model 68098
Manufacturer/Model Kubota
®
V2403-M-T E3B
Engine Type 4-stroke, diesel
Fuel Requirement No. 2-D diesel fuel (Cetane Rating-45)
Number of Cylinders/Configuration 4, in-line
Displacement
cu in. (cc) 148.5 (2434)
Bore x Stroke
in. (mm) 3.43 x 4.031 (87.0 x 102.4)
Power Output
hp (kW) 56.2 (41.9) @ 2700 rpm
Firing Order 1-3-4-2
Compression Ratio 23:1
Injection Timing (Before T.D.C.) 8.3°
Cooling System liquid cooled
Cooling System Capacity
qt (L) 8 (7.6)
Idle Speed 750 rpm
Maximum Speed (No Load) 2850 rpm
Oil Sump Capacity
qt (L) 10 (9.5)
Alternator 12 volt, 40 amp
Dry Weight
lb (kg) 419 (190)
