STEERING
4181383 First Edition 7-17
7
Steering Tower
Removal and Installation
See Figure 7-19.
Figure 7-19
1 Hex Bolt 4 Tilt Cable 7 Tilt Spring Release Bracket 10 Hex Bolt
2 Steering Tower 5 Platform 8 Lock Nut 11 Lock Nut
3 Steering Tilt Control 6 Flanged Lock Nut (4) 9 Tilt Gas Spring 12 Steering Column
TN1445
11
10
8
6
7
4
2
5
1
9
3
12
