Textron Jacobsen AR-5 Technical/Repair Manual

7-2 4181383 First Edition
STEERING
7
Specifications
Test Specifications
Steering System Leakage Test—
Cylinder Leakage
pt (L) Zero—Nominal Amount
Repair Specifications
Steering Wheel Nut lb-ft (N·m) 25—30 (34—41)
Steering Cylinder Ball Joint-to-
Steering Arm Torque
lb-ft (N·m) 80—110 (108—149)
Tie Rod Ball Joint-to-Steering Arm
Torque
lb-ft (N·m) 30—35 (41—47)
Rear Axle Alignment Toe-In
Measurement
in. (mm) 0.0625 in (1.6)
Rear Axle Spindle Arm-to-Axle
Stop Measurement
in. (mm) 0.50 (13)
Rear Axle Steering Arm-to-Motor
Mount Bolt Torque
lb-ft (N·m) 90—100 (122—136)
Steering Valve Port Cover-to-Port
Manifold Nut Torque
lb-ft (N·m) 20—24 (27—33)
Steering Valve Rotor-to-Stator
Clearance
in. (mm) 0.003 (0.08)
