THOMSON Amethyst III User Manual

Chapter 3 ’Web Browser Interface’ — Interface Description
Amethyst III DTV Smart Switch 143
User Manual
TR 101 290 Level 3 (DVB)
TR 101-290 Level 3 is a set of optional parameters that may be interesting
for certain applications.
TR 101-290 level 3 are all supported except 3.2 (SI_repetition_error), 3.3
(
Buffer_error), 3.9 (Empty_buffer_error) and 3.10 (Data_delay_error).
Available in AMETH3-LIC-SWITCH-ADV
Table 3-11. TR 101 290 Level 3 (DVB)
Format Persistence
Test Description
ASI 310M GigE Optional/Mandatory Duration Upper threshold Lower threshold
Configuration of TR 101 290 Level 3 (DVB)
PID 0x10 NIT (3.1.a.1) This test checks the Table Identifier (TID) of the sections
that are found on PID 0x10. The only
TIDs that should be
found are 0x40 (NIT actual), 0x41 (NIT other) and 0x72
(ST).
There are no specific parameters to set.
This test checks the first part of the test 3.1.a
NIT_actual_error of TR 101 290.
   M   
NIT Actual Interval
(3.1.a.2)
This test checks the periodicity of NIT actual, i.e. the
intervals between each section of the NIT actual.
An alarm is raised if the interval between two
occurrences of section 'x' of the NIT actual is greater
than the value set in the Maximum period without NIT
actual field, in milliseconds.
This test checks the 2nd part of the test 3.1.a
NIT_actual_error of TR 101 290.
   O   
NIT Other Interval (3.1.b) This test checks NIT other periodicity, i.e. the intervals
between each section of each NIT other.
An alarm is raised if the interval between two
occurrences of section 'x' of the NIT other is greater than
the value set in the Maximum period without NIT other
field, in milliseconds. Click the Add network ID button
and add the network IDs in the displayed fields.
   O   
