THOMSON Amethyst III - Input;Output Limitations

Appendix A ’Technical Specifications’ — General Device Specifications
210 Amethyst III DTV Smart Switch
User Manual
Input/Output Limitations
Table A-17. ASI platform limitations
Limitation Value
Max number of switches Maximum number allowed by license
Max number of inputs No limitation, equal to the number of inputs
available
Max number of outputs Limited by the number of available physical
outputs:
 4 if AMETH3-HW-ASI-4-1ST
 8 if AMETH3-HW-ASI-4-1ST +
AMETH3-HW-ASI-4-2ND
Max number of outputs linked to one
input
No limitation, equal to the number of outputs
Max number of outputs linked to one
switch
No limitation, equal to the number of outputs
Max number of monitored output All the outputs not explicitly configured are
considered as monitored outputs
Table A-18. IP platform limitations
Limitation Value
Max number of switches Maximum number allowed by license
Max number of inputs Twice the number of switches allowed by license
Max number of outputs Twice the number of inputs present in the
configuration
Max number of outputs linked to one
input
2
Max number of outputs linked to one
switch
4
Max number of monitored output = Max number of outputs - Number of outputs
present in the configuration
Max number of forwarding rules 64
Max number of TS over IP sessions
displayed in Discovery
512
