Chapter 3 ’Web Browser Interface’ — GUI Overview
64 Amethyst III DTV Smart Switch
User Manual
Configuration Panel
The
Configuration
panel gives access to the following tabs:
The Switches tab is mainly used to display the current state of the
switches and to perform manual switching.
The Outputs tab is used to define what content should be sent to
monitoring outputs, and to perform a switch operation on Amethyst III
with IP
interfaces.
The Tes ts tab provides a global overview of the quality of service of a
selected input. Alarms are sorted by TR 101 290 level and advanced
level.
The Automation tab is used to define the activation time of
configurations stored in the Amethyst III memory.
The Statistics tab displays several types of chart (i.e. pie chart, line
chart, stacking area chart, bar chart) that show the input streams
content and the associated bit rates.
The Ethernet, FEC tab provides statistics on an Ethernet or IP input
with FEC, if you have the FEC option.
The configuration tabs are used to edit one or more configurations.
Each tab carries the name that you defined for the configuration.
They are all described later in this section
with detailed information on
commands found in the different GUI panels.
Configuration Tabs
Purpose
The
Configuration
tabs are used to edit one or more configurations.
Once edited, the configurations are sent to the equipment for storage or
application.
Description
Configurations are listed in tabs.
Figure 3-3. List of configurations
