Appendix A ’Technical Specifications’ — Signal Processing
Amethyst III DTV Smart Switch 203
User Manual
Ethernet Control/Command
Table A-8. Gigabit Ethernet interfaces electrical specifications
Connectors 1 RJ-45 port
Speed 10/100 Base T
Control/

Monitoring
modes
 Web GUI
 Front panel
 SNMP v2
 GPIs (X6)
 Free voltage contacts (X4)
TR101.290 + Template Checking
Table A-9. TR101.290 + template checking specifications
Level of test Supported tests Availability
TR 101 290
Level 1
 1.1 TS Sync Loss
 1.2 Sync Byte Error
 1.3.a.1 PAT Interval
 1.3.a.2 PID 0 PAT
 1.3.a.3 PAT Scrambling
 1.4 Continuity Counter
 1.5.a.1 PMT Interval
 1.5.a.2 PMT Scrambling
 1.6.a PID AV Error
 1.6.b PID Other Error
Standard platform
+ Advanced
platform
TR 101 290
L
evel 2
 2.1 Transport Error
 2.2 CRC Error
 2.3.a PCR Repetition
 2.3.b PCR Discontinuity
 2.4 PCR Accuracy
 2.5 PTS Error
 2.6.1 CAT Presence
 2.6.2 PID 1 CAT
Advanced platform
