Chapter 3 ’Web Browser Interface’ — Advanced Settings
Amethyst III DTV Smart Switch 97
User Manual
You may set several associations on a same Amethyst III equipment.
However, one switch can only be part of one switches association. For
instance:
In ASI:
-
Association #1 = ASI switch #1 + ASI switch #2
-
Association #2 = ASI switch #3 + ASI switch #4
In IP:
-
Association #1 = IP switch #1 + IP switch #2 + IP switch #3
-
Association #2 = IP switch #4 + IP switch #5
-
Association #3 = IP switch #6 + IP switch #7
Switches Associations Configuration
To associate switches, proceed as follows:
1.
Select the configuration tab then go to the Switches Associations
view. Only the Associations node is displayed in the tree on the left
area of the view.
Figure 3-42. Switches Associations view
2.
In the tree on the left, right-click the Associations node, select Add and
choose Association.
Figure 3-43. Adding a Switches Association
