Chapter 1 ’Overview’ — Chassis Description
32 Amethyst III DTV Smart Switch
User Manual
F6: Information on the Product
Figure 1-20. F6 and its corresponding screen
The F6 screen contains the following information:
 Commercial reference
 Part number
 Serial number
 Version number
 Temperature
Light Front Panel
The light front panel features no screen, no button, and no buzzer. It
features only the LED panel which provides a visual indication of overall
device operation.
Figure 1-21. Amethyst III light front panel
LED panel
The front panel only features a LED panel, to inform you on Amethyst III’s
general state. The LED are described above in the
Section ’Full Front
Panel’
on page 26.
