Chapter 3 ’Web Browser Interface’ — Interface Description
Amethyst III DTV Smart Switch 169
User Manual
Resize columns: move your mouse between two column headers. The
mouse cursor should change to
. Click and drag the column to the
wanted size and then release the mouse button.
Move columns: click the column header and drag it to the new
position.
All the graph display settings are not saved. They are applet specific
and will be lost after the closure of the interface.
Charts Types Overview
In a pie chart, each slice represents an element (e.g. program, ghost
component, stuffing, program component) that is referenced in the
caption.
In a li
ne chart, each line represents an element.
A sta
cking area chart describes the rates of each element of a TS. It is very
useful to visualize the bandwidth use.
In a ba
r chart, the bit rate of each element is represented by a colored bar.
Selected Elements on Charts
One or more element may be selected. Selected elements are
highlighted in the caption and the corresponding element on the graph
is displayed in a brighter color, and off-centered from the graph on pie
charts.
To select an element, you can click the item in the caption or in the c
hart.
To select several elements, press
CTRL
while clicking the elements.
Figure 3-101
shows an example where two PIDs are selected on a
program pie chart.
