OPUS Projektor Manual
User Interface
· Project-Properties/Project-Event changes
· All dialog changes which modify the project
oSimulation-Settings
oVariable-Manager
oTerminal and Owner(ECUs) Configuration...
oPort Configuration
oConfigure Mappings Dialog
oCAN-Freestyle: Transmit-Sequences
oCAN-Freestyle: CAN-ID Masks
oJ1939: DM1/DM2 Settings
oImport Variables
oImport DBC-File
oDataType definitions
oProcess Configuration
· Current/Default Language/Unit changes
· Hide/Show object changes
· Day/Night Mode changes
Each list entry contains 3 elements:
1. Icon
2. Presentation Name
3. Tooltip
Icon
· For graphical objects the icon of the object is used which was updated.
· For communication objects the icon of the appropriate object is used
· For JS changes the JS icon is used.
· For Project-Property changes, the project icon is used.
· Simulation-Settings the PClient icon is used
· For Day/Night Mode changes the Day/Night Icon is used
· For CAN-Mapping changes the Mapping Icon is used.
· For Protocol changes the Network icon is used.
· All other changes uses the Project icon
Presentation Name
· Graphical Objects
oProperty-Changes: [<Page-Name>]: <Object-Name>: <Property-Name>
oEvent-Changes: [<Page-Name>]: <Object-Name>: <Event-Name>
oMove-Changes: [<Page-Name>]: <Object-Name>: Move
oResize-Changes: [<Page-Name>]: <Object-Name>: Resize
oAdd/Remove: : [<Page-Name>]: <Object-Name>: Add/Remove
· Communication Objects
oProperty-Changes: [Project]: <Object-Name>: <Property-Name>
oEvent-Changes: [Project]: <Object-Name>: <Event-Name>
· JS-Objects
oAdd: [JavaScripts]: <JS-FileName>: Add
oRemove: [JavaScripts]: <JS-FileName>: Remove
