OPUS Projektor Manual
Quick Start Tutorial
For the navigation from the Gauges Page to the Configuration Page please follow the
same steps (56 to 69) to configure one of the softkeys of the Configuration page. The
result should look like this:
Let the User change the value
The display user shall be able to change the display backlight intensity. Here is what needs
to be done:
· Drag the Linear Bargraph from the Palette (70) to the page editor (71).
Change the following Properties of the Linear Bargraph:
· X Location: 239
· Y Location: 110
· Width: 164
· Height: 20
