OPUS Projektor Manual
User Interface
When a project is loaded and the project contains warnings, the search tab will be opened
automatically, showing all warnings in the project.
Don't discard these warnings! It might be nothing important, but more often than not
something is not right in the project if warnings are shown, so please check them.
Objects can be renamed in the project tree by selecting them and pressing F2, or clicking on
them again after selecting them.
Pages can be moved in the project tree to change their order for a better project overview.
With <Alt> + <PgUp> / <Alt> + <PgDn> pages can be moved one step higher / lower.
With <Alt> + <Pos1> / <Alt> + <End> pages can be moved to the top / bottom.
The Alarms category contains all alarms in the project.
The Communication category contains all variables and CAN mappings sorted by owner /
protocol. Note that CAN mappings can be deleted in bulk here.
The Virtual Keyboards category contains the virtual keyboards used in the project.
The JavaScripts category contains all Javascript files in the project. Files can be copied
and deleted here as well as dragged & dropped onto objects.
The Images category contains the Image Pool , all images that are used in the project.
Page Editor (4)
The Page Editor allows the design of the graphical user interface.
Satellite Window (5)
The satellite window shows the whole display device and the viewing part visible in the editor.
It is useful for a fast navigation when the page editor is zoomed in and only shows a small
piece of the whole display.
Variable View (6)
The Variable View allows viewing, creation and editing of variables. Furthermore it can be
used to easily link a variable with an object in the editor by dragging & dropping the variable
to the object.
Palette (7)
The palette contains all the graphical objects that can be dragged & dropped into the
editor.
Properties Window (8)
The property window shows all the properties available for the currently selected object.
Output (9)
The output window provides information, warnings and errors that occur while using the
program. They might help finding the root cause if you run into trouble.
It will also show results of J1939 DM1/DM2 translation file validations.
Also, system console outputs from the PClient simulation will be printed here.
Reported Issues (10)
