OPUS Projektor Manual
Object Reference
Line1Column1;Line1Column2;Line1Column3;Line1Column4
Line2Column1;Line2Column2;Line2Column3;Line2Column4
Line3Column1;Line3Column2;Line3Column3;Line3Column4
The source for the text can either be automatic (e.g. from J1939 DM settings) or set manually
via a JavaScript (set the text directly (with setProperty and property "Table Data") or read e.g.
a log file, see JavaScript readFile function for an example).
It is not possible to give a preview of the text in the designer tool. The text will be only available
at runtime.
Properties of the table
General
The table shares the same general properties with all other objects.
The table may not be language or unit dependent.
Variable References
Variable Reference
Here a number variable can be assigned to the table. With this variable the table can be
scrolled if the content can not be dsiplayed completely. Set value 0 to scroll to top, any
other value will scroll the value down (depending on number of lines in the table).
Default: No Variable
Possible Values: Any number variable
Bit Mask
Same as for other objects.
Skin Properties
Skin properties are the same as for other objects.
Visibility
Visibility properties are the same as for other objects.
Input Configuration
The input configuration properties are the same as for other objects. Like with an assigned
variable it is possible to manually scroll through the table if the property Set As Input is
enabled.
Value Related
The Preview Value property will have no influence on the table in the tool. With JavaScript
you could set that property to scroll through the table but it is recommended to just set the
property Set As Input or attach a variable for scrolling.
Formatting
Font Attribute
Same as for other objects. The font attribute selected here will be applied to the text shown
in the table.
Font
Same as for other objects. The font selected here is used as the font for the table's text.
