Setting
RFID channels — process output data
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 104
Process output data — HF bus mode operating mode
Byte no. Bit
PROFINET Modbus
EtherNet/
IP
7 6 5 4 3 2 1 0
Channel 0
n + 0 0 Command code (CMDC)
n + 1 1
n + 2 2 Loop counter for rapid processing (RCNT)
n + 3 3 Memory area (DOM) — only available with UHF applications
n + 4 4 Start address (ADDR)
n + 5 5
n + 6 6
n + 7 7
n + 8 8 Length (LEN)
n + 9 9
n + 10 10 Length of UID/EPC (SOUID)
n + 11 11 Reserved
n + 12 12 Timeout (TOUT)
n + 13 13
n + 14 14 Read fragment No. (RFN)
n + 15 15 Write fragment No. (WFN)
n + 16 16 Reserved
n + 17 17 Reserved
n + 18 18 Reserved
n + 19 19 Reserved
n + 20 20 Read/write head address (ANTN) — only available with HF applications
n + 21 21 Reserved
n + 22 22 Reserved
n + 23 23 Reserved
n + 24 24 Write data Byte 0
n + 25 25 Write data Byte 1
n + 26 26 Write data Byte 2
n + 27 27 Write data Byte 3
n + 28 28 Write data Byte 4
n + 29 29 Write data Byte 5
n + 30 30 Write data Byte 6
n + 31 31 Write data Byte 7
… … …
n + 151 151 Write data Byte 127
Channel 1
n + 152…
303
152…303 Assignment identical to channel 0
