8.8.30 Command: Get HF tag protection status
NOTE
The command is only available for applications with the HF tags with chip types
EM42… and NXP SLIX2.
The Get HF tag protection status command queries with a direct command whether a specific
area of the tag is password protected. When sending the command only one tag can be loc-
ated in the detection range of the read/write head.
In HF applications, the password function is available in single-tag mode only. A fault signal is
output with multitag applications. To troubleshoot, set the HF: multitag parameter to 0: multi-
tag mode off.
See description of the output data, p. [}105].
Request
Loop counter See description of the output data
Command code 0x0104 (hex.), 260 (dec.)
Read/write head address See description of the output data
Length UID/EPC The UID or EPC size should be entered in bytes if a particular
tag is to be protected. The UID or EPC must be defined in the
write data (start byte: 0). The function of the UID/EPC length
is dependent on the command used.
0: The command is executed for the tag which is located in
the detection range of the read/write head.
> 0: EPC length of the tag to be protected if an EPC is
present in the write data
-1: NEXT mode: A tag is only ever protected if the UID/EPC
differs from the UID/EPC of the tag last read or written to.
Start address Not required
Length 8 byte
Timeout See description of the output data
Write fragment No. 0
Read fragment No. See description of the output data
Write data Not required
See description of the input data, p. [}100].
Response
Loop counter See description of the input data
Response code 0x0104 (hex.), 260 (dec.)
Length Not required
Error code See description of the input data
Tag in
detection range
See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. 0
Read fragment No. See description of the input data
