8.1 RFID channels — parameter data
Byte no. Bit
7 6 5 4 3 2 1 0
Channel 0
0 Operation mode (OMRFID)
1 Select tag type (TAGTYPE)
2 Bypass time (BYPASS)
3
4 AT TERM HB ANTI
5 DDI DXD
6 HFIDLEMODE
7 Reserved
8 Command retries (CRET)
9 HF: Command in Continuous Mode (CCM)
10 HF: Length in Continuous Mode (LCM)
11
12 HF: Address in Continuous Mode (ACM)
13
14
15
16 Reserved
17…26 …
27 Reserved
28 XCVR8 XCVR7 XCVR6 XCVR5 XCVR4 XCVR3 XCVR2 XCVR1
29 XCVR16 XCVR15 XCVR14 XCVR13 XCVR12 XCVR11 XCVR10 XCVR9
30 XCVR24 XCVR23 XCVR22 XCVR21 XCVR20 XCVR19 XCVR18 XCVR17
31 XCVR32 XCVR31 XCVR30 XCVR29 XCVR28 XCVR27 XCVR26 XCVR25
32 Length of read data (RDS)
33
34 Length of write data (WDS)
35
Channel 1
36…71 Assignment identical to channel 0
