Connection
Connecting a device in zone 2 and zone 22
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 23
6 Connection
NOTICE
Penetration of liquids or foreign objects due to leaking connections
Loss of protection class IP65/IP67/IP69K possible
Tighten M8 male connectors with a tightening torque of 0.4 Nm.
Tighten M12 male connectors with a tightening torque of 0.6 Nm.
Only use accessories that guarantee the protection class.
Provide unused male connectors with suitable sealing or blanking caps. The
tightening torque for the M4 screws is 0.5Nm.
6.1 Connecting a device in zone 2 and zone 22
DANGER
Potentially explosive atmosphere
Risk of explosion due to spark ignition
Operation in zone 2 or zone 22:
Only connect and disconnect circuits when no voltage is present.
Only use connection cables suitable for use in the potentially explosive areas.
Use unused male connectors or provide them with suitable sealing or blanking
caps. The tightening torque for the M4 screws is 0.5 Nm.
Observe the requirements for Ex approval.
