turck TBEN-RFID Series User Manual

Operation
Using function blocks for Siemens TIA portal
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 238
9.12 Using function blocks for Siemens TIA portal
Three function blocks are provided for the simple integration in (existing) programs in the TIA
Portal:
n RFID_COMPACT_Mode
n RFID_EXTENDED_Mode
n RFID_HF_Busmode
Function block Operation mode
RFID_COMPACT_Mode HF compact
UHF compact
RFID_EXTENDED_Mode HF extended
UHF extended
RFID_HF_Busmode HF bus mode
The function blocks can be downloaded as elements of example programs free of charge at
www.turck.com. The example programs are available for TIA V15 and TIA V16 and the Siemens
S7-1200 and S7-1500 controllers.
The required command can be selected via the FC10 and FC20 functions. Further parameters
can be set at the function blocks FB10 (Compact), FB11 (Extended) and FB12 (HF bus mode).
xCmdRead
xCmdWrite
xCmdReset
xCmdInventory
xCmdTagInfo
xCmdDirectExecute
wDirectCommandCode
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
HEX
HEXwCMDC
FC10
Fig.147: FC10 function block
HwID_HFcompact
CMDC
RCNT
DOM
ADDR
LEN
SOUID
HwID_Read016B
HwID_Write016B
WriteDataBuffer 16B
DEC
HEX
DEC
DEC
DEC
DEC
DEC
DEC
DEC
POINTER
HEX
BOOL
BOOL
DEC
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
DEC
HEX
DEC
POINTER
RESC
BUSY
ERROR
RCNT_F
TP1
XDx
PNSx
TREx
TNCx
TONx
CMON
LEN_F
ERRC
TCNT
ReadDataBuffer 16B
FB10
Fig.148: FB10 function block
