turck TBEN-RFID Series User Manual

Operation
Using function blocks for Siemens TIA portal
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 239
HwID_HFextended
CMDC
RCNT
DOM
ADDR
LEN
SOUID
TOUT
RFN
WFN
HwID_Read128B
HwID_Write128B
WriteDataBuffer 128B
DEC
HEX
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
POINTER
HEX
BOOL
BOOL
DEC
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
DEC
HEX
DEC
DEC
DEC
DEC
POINTER
RESC
BUSY
ERROR
RCNT_F
TP1
XDx
PNSx
TREx
TNCx
TONx
CMON
LEN_F
ERRC
TCNT
BYFI
RFN_F
WFN_F
ReadDataBuffer 128B
FB11
Fig.149: FB11 function block
HwID_HFbusmode
CMDC
RCNT
DOM
ADDR
LEN
SOUID
TOUT
RFN
WFN
ANTIN
HwID_Read128B
HwID_Write128B
WriteDataBuffer 128B
DEC
HEX
DEC
DEC
DEC
DEC
DEC
DEC
DEC
DEC
BYTE
DEC
DEC
POINTER
HEX
BOOL
BOOL
DEC
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
BOOL
DEC
HEX
DEC
DEC
DEC
DEC
DWORD
POINTER
RESC
BUSY
ERROR
RCNT_F
TP1
XDx
PNSx
TREx
TNCx
TONx
CMON
LEN_F
ERRC
TCNT
BYFI
RFN_F
WFN_F
TP_ALL
ReadDataBuffer 128B
FB12
Fig.150: FB12 function block
Input variables — FC10 and FC11
Name Data type Meaning
xCmdRead BOOL
0 Ò 1 Ò 0: Executing a read command
xCmdWrite BOOL
0 Ò 1 Ò 0: Execute write command
xCmdReset BOOL
0 Ò 1 Ò 0: Reset command
xCmdInventory BOOL
0 Ò 1 Ò 0: Executing the Inventory command
xCmdTagInfo BOOL
0 Ò 1 Ò 0: Execute Tag info command
xCmdDirectExecute BOOL
0 Ò 1 Ò 0: Execute direct command
wDirectCommandCode HEX Command code of the direct command
