Appendix: flow charts showing the operation of the device
Flow chart: Continuous Mode without interruption before reading data
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 283
15.5 Flow chart: Continuous Mode without interruption before reading data
Data bytes available = 0
ERROR= TRUE
Error Code
Read-Fragment +1
Yes
No
Idle:
Command Code = 0
Response Code = 0
Response Code = Command Code
Set parameter:
„Length“ : define value
Set command:
Command Code := 0x0011
Set command:
Command Code := 0x0010
Set command:
Command Code := 0x0012
Set command:
Command Code := 0x0010
Set output parameter:
- „Start address“ := 1
(Grouping EPCs for UHF)
Yes
…
*)
*) After increasing the Read Fragment No., the new data will be shown in the read data input.
Fig.179: Flow chart for Continuous Mode without interruption before reading data
