turck TBEN-RFID Series User Manual

Setting
Digital channels — setting extended parameters (EXT LEAN)
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 107
8.4 Digital channels — parameter data
Byte no. Bit
7 6 5 4 3 2 1 0
0 SRO7 SRO6 SRO5 SRO4
1 OE7 OE6 OE5 OE4
8.4.1 Meaning of the parameter bits
Default values are shown in bold.
Designation Meaning
Manual reset after overcurrent
(SRO…)
0: No (the output automatically switches back on after an overcurrent.)
1: Yes (the output only switches back on after the overcurrent is removed and
the switch signal is reset.)
Activate output (OE…)
0: No (output deactivated)
1: Yes (output activated)
8.5 Digital channels — setting extended parameters (EXT LEAN)
Byte no. Bit
7 6 5 4 3 2 1 0
0 DIFT DMOD (Byte 1…7)
1 IST (Byte 0…8)
8.5.1 Meaning of the parameter bits
Default values are shown in bold.
Designation Meaning
Input filter (DIFT) The input filter determines how long a change at the input must be present be-
fore it is transferred to the input data.
0: 0.2 ms
1: 3 ms
Extended digital mode (DMOD)
0: Deactivated
1: Digital filter and impulse stretch activated
Impulse stretch (IST) Impulse stretch: 0…2550 ms (adjustable in 10 ms steps), default value: 10 ms
