8.8.19 Command: Tune HF read/write head
NOTE
The command is only available for the TNLR-… and TNSLR-… HF read/write heads.
The Tune Read/write head command enables HF read/write heads to be tuned automatically
to their ambient conditions. The tuning values are saved until the next voltage reset in the
read/write head.
HF read/write head tuning is carried out automatically by default after each voltage reset.
See description of the output data, p. [}105].
Request
Loop counter See description of the output data
Command code 0x0080 (hex.), 128 (dec.)
Read/write head address See description of the output data
Length UID/EPC Not required
Start address Not required
Length Not required
Timeout See description of the output data
Write fragment No. 0
Read fragment No. See description of the output data
Write data Not required
See description of the input data, p. [}100].
Response
Loop counter See description of the input data
Response code 0x0080 (hex.), 128 (dec.)
Length 2
Error code See description of the input data
Tag in
detection range
See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. 0
Read fragment No. See description of the input data
Read data, byte 0 Tuning value:
TNLR-…: 0x00…0x0F
TNSLR-…: 0x00…0x1F
Read data, byte 1 Received voltage value (0x00…0xFF)
