8.6 Digital channels — process input data
Byte no. Bit
7 6 5 4 3 2 1 0
0 DXP7 DXP6 DXP5 DXP4
1
8.6.1 Meaning of the status bits
Designation Meaning
DXP4 0: Off (digital channel 1 not active)
1: On (digital channel 1 active)
DXP5 0: Off (digital channel 2 not active)
1: On (digital channel 2 active)
DXP6 0: Off (digital channel 3 not active)
1: On (digital channel 3 active)
DXP7 0: Off (digital channel 4 not active)
1: On (digital channel 4 active)
8.7 Digital channels — process output data
Byte no. Bit
7 6 5 4 3 2 1 0
0 DXP7 DXP6 DXP5 DXP4
1
8.7.1 Meaning of the command bits
Default values are shown in bold.
Designation Meaning
DXP4
0: Off (switch off digital channel 1)
1: On (switch on digital channel 1)
DXP5
0: Off (switch off digital channel 2)
1: On (switch on digital channel 2)
DXP6
0: Off (switch off digital channel 3)
1: On (switch on digital channel 3)
DXP7
0: Off (switch off digital channel 4)
1: On (switch on digital channel 4)
