14 Technical Data
Technical Data
Power supply
Power supply voltage 24 VDC
Permissible range 18…30 VDC
Total current max. 4 A per voltage group
Total current V1 + V2 max. 5.5 A at 70 °C per
module
Voltage supply connection 2 × M8, 4-pin
Operating current V1: max. 120 mA
V2: max. 30 mA
RFID power supply Sockets C0…C1 from V1 short-circuit proof,
1.2 A ≤ 55°C, 55°C < 0.5A ≤ 70°C per channel
Sensor/actuator supply Sockets C2…C3 from V2 short-circuit proof,
0.14A < 55°C, 55°C < 0.05A < 70°C
Potential isolation Potential isolation of V1 and V2 voltage group
Voltage proof up to 500 VDC
System data
Ethernet transfer rate 10 Mbit/s / 100 Mbit/s
Ethernet connection technology 2 × M8, 4-pin, D-coded
Protocol detection automatic
Web server Default: 192.168.1.254
Service interface Ethernet via P1 or P2
Field Logic Controller (FLC)
ARGEE firmware version 3.3.5.0
ARGEE engineering version 2.0.26.0
Modbus TCP
Addressing Static IP, BOOTP, DHCP
Supported function codes FC1, FC2, FC3, FC4, FC5, FC6, FC15, FC16, FC23
Number of TCP connections 8
Input register start address 0 (0x0000)
Output register start address 2048 (0x0800)
EtherNet/IP
Addressing As per EtherNet/IP specification
Quick Connect (QC) < 500 ms
Device Level Ring (DLR) Supported
Class 3 connections (TCP) 3
Class 1 connections (CIP) 10
Input assembly instance 103
Output assembly instance 104
Configuration assembly instance 106
