turck TBEN-RFID Series User Manual

Technical Data
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 276
Technical Data
PROFINET
Addressing DCP
Conformity class B (RT)
MinCycleTime 1 ms
Fast startup (FSU) < 500 ms
Diagnostics According to PROFINET Alarm Handling
Topology detection Supported
Automatic addressing Supported
Media redundancy protocol (MRP) Supported
System redundancy S2
RFID
No. of channels 2
Connection technology M12
Power supply 1.2 A ≤ 55 °C, 55 °C < 0.5 A ≤ 70 °C per channel,
short-circuit proof
Operation per channel 1 × HF or read/write head or UHF reader, up to
32 bus-capable HF read/write heads with
suffix / C53 (if necessary, additional power feed
required)
RFID data interface HF and UHF
Cable length Max. 50 m
Digital inputs
No. of channels 4
Connection technology of inputs M12, 5-pin
Input type PNP
Type of input diagnostics Channel diagnostics
Switch threshold EN 61131-2 Type 3, PNP
Signal voltage Low signal < 5 V
Signal voltage High signal > 11V
Signal current Low signal < 1.5 mA
Signal current High signal > 2 mA
Input delay 0.05 ms
Potential isolation Galvanic isolation from the fieldbus, voltage
proof up to 500 VDC
Digital outputs
No. of channels 4
Connection technology of outputs M12, 5-pin
Output type PNP
Type of input diagnostics Channel diagnostics
Output voltage 24 VDC from potential group V2
Output current per channel 0.5 A, short-circuit resistance
Utilization factor 1 (0.03 > 55 °C)
Load type EN 60947-5-1: DC-13
Short-circuit protection yes
