turck TBEN-RFID Series - Connecting the Device Online with the Controller; Reading out Process Data

Commissioning
Connecting the device to a Modbus master with CODESYS
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 47
7.2.6 Connecting the device online with the controller
 Select device.
 Click Online Ò Login.
7.2.7 Reading out process data
The process data can be interpreted using mapping if the device is connected online with the
controller.
 Double-click the Modbus TCP slave.
 Click the Modbus TCP slave I/O image tab.
a The process data is displayed.
Fig.46: Process data
