9.15 Software diagnostic messages
9.15.1 Diagnostic messages — gateway functions
Byte no. Bit
7 6 5 4 3 2 1 0
0 FCE COM V1
1 V2 ARGEE DIAG
Meaning of the diagnostic bits
Designation Meaning
V2 Undervoltage V2
ARGEE ARGEE program active
DIAG Module diagnostics available
FCE DTM active in Force mode
COM Internal error
V1 Undervoltage V1
9.15.2 Diagnostic messages — RFID channels
Byte no. Bit
7 6 5 4 3 2 1 0
0 VAUX PRMER DTM FIFO
1 Reserved
2 Reserved
3 Reserved
4 TNC1 TRE1 PNS1 XD1
5 TNC2 TRE2 PNS2 XD2
6 TNC3 TRE3 PNS3 XD3
… … … … …
35 TNC32 TRE32 PNS32 XD32
Meaning of the diagnostic bits
Designation Meaning
VAUX Overvoltage VAUX
PRMER Parameterization error
DTM Configuration via DTM active
FIFO Buffer full
TNC… Expected read/write head not connected
(only functions in bus mode or with activated parameter HF: Heartbeat read/
write head) is activated
TRE… Read/write head reports error
PNS… Parameter not supported by read/write head
XD… Antenna detuned
