Setting
Setting RFID interfaces via the web server
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 170
8.9 Setting RFID interfaces via the web server
NOTE
The web server always shows all setting options. All values are shown as decimal val-
ues.
The devices can be set and commands sent to the devices via the integrated web server. To
open the web server with a PC, the device and the PC must be located in the same IP network.
8.9.1 Opening a web server
The web server can either be opened via a web browser or via the Turck Service Tool. The call of
the web server via the Turck Service Tool is described in the section “Adjusting network set-
tings”.
The device is factory set to IP address 192.168.1.254. To open the web server via a web browser,
enter http://129.168.1.254 in the address bar of the web browser.
Status information and network settings are displayed on the home page.
Fig.79: Example: Web server — home page
