turck TBEN-RFID Series User Manual

Setting
RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 146
8.8.20 Command: Read AFI from HF tag
The AFI byte of an HF tag can be read out using the Read AFI from HF tag command.
NOTE
The command is supported by HF read/write heads revision xV99 or later.
See description of the output data, p. [}105].
Request
Loop counter See description of the output data
Command code 0x0090 (hex.), 144 (dec.)
Read/write head address See description of the output data
Length UID/EPC Not required
Start address Not required
Length Not required
Timeout See description of the output data
Write fragment No. 0
Read fragment No. See description of the output data
Write data Not required
See description of the input data, p. [}100].
Response
Loop counter See description of the input data
Response code 0x0090 (hex.), 144 (dec.)
Length Not required
Error code See description of the input data
Tag in
detection range
See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. 0
Read fragment No. See description of the input data
Read data, byte 0 AFI
Read data, Byte 1…(Length - 1) Not required
