turck TBEN-RFID Series User Manual

Setting
RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 136
8.8.15 Command: Tag info
NOTE
The command code for rapid processing with the loop counter is 0x2050 (hex.) or
8272 (dec.).
The Tag info command enables the chip information of a HF tag to be queried. With HF applic-
ations, the command is available with automatic detection only. In UHF applications, the alloca-
tion class identifier, tag mask design identifier and tag model number are queried. The data is
queried from the GSI record of the tag.
See description of the output data, p. [}105].
Request
Loop counter See description of the output data
Command code 0x0050 (hex.), 80 (dec.)
Read/write head address See description of the output data
Length UID/EPC Not required
Start address Start address in the GSI record
Length Length of the system data read (bytes)
0: All system data is read.
Timeout Not required
Write fragment No. Not required
Read fragment No. See description of the output data
Write data Not required
See description of the input data, p. [}100].
Response (HF)
Loop counter See description of the input data
Response code 0x0050 (hex.), 80 (dec.)
Length See description of the input data
Error code See description of the input data
Tag in
detection range
See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. 0
Read fragment No. See description of the input data
Read data, bytes 0…7 UID, MSB (always 0xE0)
Read data, byte 8 DSFID (data storage format identifier)
Read data, byte 9 AFI (application identifier)
Read data, byte 10 Memory size: Block number (0x00…0xFF)
Read data, byte 11 Memory size: Byte/block (0x00…0x1F)
Read data, byte 12 IC reference
