turck TBEN-RFID Series User Manual

Setting
RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 137
Response (UHF)
Loop counter See description of the input data
Response code 0x0050 (hex.), 80 (dec.)
Length See description of the input data
Error code See description of the input data
Tag in detection range See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. 0
Read fragment No. See description of the input data
Read data, bytes 0…3 First 32 bytes of the TID (tag class, manufacturer and chip
type)
Read data, bytes 4…n EPC (variable length)
Chip information on the UHF tags
Name TID memory Size (Bits)
Allocation
class
identifier
Tag mask
designer
Tag model
number
EPC TID USER
Alien Higgs-3 0xE2 0x003 0x412 96…480 96 512
Alien Higgs-4 0xE2 0x003 0x414 16…128 96 128
NXP U-Code G2XM 0xE2 0x006 0x003 240 64 512
NXP U-Code G2XL 0xE2 0x006 0x004 240 64 –
NXP U-Code G2iM 0xE2 0x006 0x80A 256 96 512
NXP U-Code G2iM+ 0xE2 0x006 0x80B 128…448 96 640…320
NXP U-Code G2iL 0xE2 0x006 0x806, 0x906, 0xB06 128 64 –
NXP U-Code G2iL+ 0xE2 0x006 0x807, 0x907, 0xB07 128 64 –
NXP U-Code 7 0xE2 0x806 0x890 128 96 –
NXP U-Code 7xm (2k) 0xE2 0x806 0xF12 448 96 2048
Impinj Monza 4E 0xE2 0x001 0x10C 496 96 128
Impinj Monza 4D 0xE2 0x001 0x100 128 96 32
Impinj Monza 4QT 0xE2 0x001 0x105 128 96 512
Impinj Monza 5 0xE2 0x001 0x130 128 96 –
Impinj Monza R6 0xE2 0x001 0x160 96 96 –
Impinj Monza R6-P 0xE2 0x001 0x170 128 96 64
