turck TBEN-RFID Series User Manual

Operation
LEDs
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 244
TP0 and TP1 LEDs Meaning
Off No tag within the detection range
Green Tag present at read/write head
Green flashing Tag present at read/write head, command is processed
Flashing (1 Hz) red/
green
Connection with DTM. No connection to controller active.
Red Diagnostics present
RFID channel LEDs Meaning
TP… and CMD… flash
simultaneously
Auxiliary power overload
TP… and CMD… flash
alternately
Parameter error
DXP channel LEDs Meaning (input) Meaning (output)
Off No input signal Output not active
Green Input signal present Output active (max. 0.5A)
Red – Actuator overload
Flashing red (1Hz) Auxiliary power overload
Flashing white (DXP7
only)
Wink command active
