turck TBEN-RFID Series User Manual

Setting
RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 112
Overview of output data
See description of the output data, p. [}105].
Request
Loop counter Not required
Command code 0x0000 (hex.), 0 (dec.)
Read/write head address Not required
Length UID/EPC Not required
Start address Not required
Length Not required
Timeout Not required
Write fragment No. Not required
Read fragment No. Not required
Write data Not required
Overview of input data
See description of the input data, p. [}100].
Response
Loop counter See description of the input data
Response code 0x0000 (hex.), 0 (dec.)
Length Length of the UID/EPC of the tag in the detection range
Error code See description of the input data
Tag in
detection range
See description of the input data
Data (bytes) available See description of the input data
Tag counter See description of the input data
Write fragment No. Size of the fragment
Read fragment No. Size of the fragment
Read data, bytes 0…n UID/EPC of the tag in the detection range
Example: UID, HF bus mode
Type Name Meaning
uint8_t Data [8] uint8_t UID [8]
uint8_t Reserved Reserved
uint8_t Address Address of the read/write head
Example: successful read command (64 bytes), HF bus mode
Type Name Meaning
uint8_t Data [64] uint8_t read data [64]
uint8_t Reserved Reserved
uint8_t Address Address of the read/write head
