RFID channels — overview of commands
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 139
Example: Direct command in HF applications (query read/write head version)
Request
Loop counter 0
Command code 0x0060
Read/write head address 0
Length UID/EPC 0
Start address 0
Length 2
Timeout 200
Write fragment No. 0
Read fragment No. 0
Write data 0xE0 (CC), 0x00 (CI) — see BL ident protocol
Response
Loop counter 0
Response code 0x0060
Length 6
Error code 0
Tag in
detection range
0
Data (bytes) available 0
Tag counter 0
Write fragment No. 0
Read fragment No. 0
Read data 0xE0 (CC), 0x00 (CI), 0x04, 0x06, 0xA1, 0x77
The BL ident protocol can be used to query the following information with the bytes written to:
n Byte 5, read/write head ID 4
n Byte 6, hardware version 6
n Byte 7, software version x.y, x (A1)
n Byte 8, software version x.y, y (0x77)
n The entire software version information consists of byte 7 and byte 8 (A1v77).
