turck TBEN-RFID Series User Manual

Operation
HF applications — using HF Continuous Bus Mode
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 225
 To stop Continuous Mode, execute the Stop Continuous Mode command (0x0012).
or
 To stop Continuous Mode and clear the FIFO memory of the interface, send the Reset
command (0x0800).
NOTE
The data must be passed on regularly from the device to the parent level. No other
data can be stored if the 16 Kbyte ring memory is full. The device outputs an error
message.
User data areas of HF tags
Refer to the data sheets of the tags for the relevant chip types.
Chip type User data area Access Bytes per block
First block Last block Total memory
in bytes
NXP SLIX2 0x00 0x4E 316 Read/write 4
NXP Icode SLIX 0x00 0x1B 112 Read/write 4
NXP Icode SLIX-S 0x00 0x27 160 Read/write 4
NXP Icode SLIX-L 0x00 0x07 32 Read/write 4
Fujitsu MB89R118
Fujitsu MB89R118B
0x00 0xF9 2000 Read/write 8
Fujitsu MB89R112 0x00 0xFF 8192 Read/write 32
TI Tag-it HF-I Plus 0x00 0x3F 256 Read/write 4
TI Tag-it HF-I 0x00 0x07 32 Read/write 4
Infineon SRF55V02P 0x00 0x37 224 Read/write 4
Infineon SRF55V10P 0x00 0xF7 992 Read/write 4
EM4233 0x00 0x33 208 Read/write 4
EM4233 SLIC 0x00 0x1F 128 Read/write 4
