turck TBEN-RFID Series User Manual

Operation
Using function blocks for Siemens TIA portal
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 241
Output variables — FB10 and FB11
Name Data type Meaning
RESC HEX Response code, see description of the input
data, [}100]
BUSY BOOL Status of the command execution, see descrip-
tion of the input data, [}100]
ERROR BOOL Error, see description of the input data, [}100]
RCNT_F DEC Loop counter for fast processing, see descrip-
tion of the input data, [}100]
TP1 BOOL Tag present, see description of the input data,
[}100]
XDx BOOL HF read/write head at address x detuned, see
description of the input data, [}100]
PNSx BOOL Parameter of read/write head at address x not
supported, see description of the input data,
[}100]
TREx BOOL Read/write head at address x reports error, see
description of the input data, [}100]
TNCx BOOL Expected read/write head with address x not
connected, see description of the input data,
[}100]
TONx BOOL HF read/write head switched on, see descrip-
tion of the input data, [}100]
CMON BOOL Continuous (Presence Sensing Mode) active,
see description of the input data, [}100]
LEN_F DEC Length, see description of the input data,
[}100]
ERRC HEX Error code, see description of the input data,
[}100]
TCNT DEC Tag counter, see description of the input data,
[}100]
BYFI
(RFID_EXTENDED_Mode)
DEC Data (bytes) available, see description of the
input data, [}100]
RFN_F
(RFID_EXTENDED_Mode)
DEC Read fragment No., see description of the in-
put data, [}100]
WFN_F
(RFID_EXTENDED_Mode)
DEC Write fragment No., see description of the in-
put data, [}100]
TP_ALL
(RFID_HF_Busmode)
DWORD Tag in the detection range of the connected
read/write head, [}100]
ReadDataBuffer 16B
(RFID_COMPACT_Mode)
ReadDataBuffer 128B
(RFID_EXTENDED_Mode)
(RFID_HF_Busmode)
DEC Read data
