turck TBEN-RFID Series User Manual

Setting
RFID channels — process input data
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | more@turck.com | www.turck.com
07.00 | 2022/09 | 98
Process input data — HF extended and UHF extended modes
Byte no. Bit
PROFINET Modbus
EtherNet/
IP
7 6 5 4 3 2 1 0
Channel 0
n + 0 0 Response code (RESC) incl. ERROR and BUSY
n + 1 1
n + 2 2 Loop counter for rapid processing (RCNT)
n + 3 3 Reserved
n + 4 4 TNC1 TRE1 PNS1 XD1 TP
n + 5 5 CMON TON
n + 6 6 Length (LEN)
n + 7 7
n + 8 8 Error code (ERRC)
n + 9 9
n + 10 10 Tag counter (TCNT)
n + 11 11
n + 12 12 Data (bytes) available (BYFI)
n + 13 13
n + 14 14 Read fragment No. (RFN)
n + 15 15 Write fragment No. (WFN)
n + 16 16 Reserved
n + 17 17 Reserved
n + 18 18 Reserved
n + 19 19 Reserved
n + 20 24 Read data Byte 0
n + 21 25 Read data Byte 1
n + 22 26 Read data Byte 2
n + 23 27 Read data Byte 3
n + 24 28 Read data Byte 4
n + 25 29 Read data Byte 5
n + 26 30 Read data Byte 6
n + 27 31 Read data Byte 7
… … …
n + 147 151 Read data Byte 127
Channel 1
n + 148…
295
152…303 Assignment identical to channel 0
