1180
89.2
Model
No Page
AIR CONDITIONING, FIT TING INSTRUCTION
(PT94--- cabin) 30.07.1999
10(28)
28.06.1999
6000---8750
6250Hi---8950Hi
--- G lu e s e a l 66 onto the housing bottom at the
evaporator rear edge (see picture).
Glue seals 47 and 67 onto the gables of the
evaporator.
--- Fit the heater radiator and connect the hoses
(renew the clips if necessary). Check that the
hose lead---in point on the housing a re fully tight.
--- Pa s s c ov e r i n g 39 for the hoses to the evapor-
ator. Pass the hoses above the cab attachment
and push these hoses up inside the cab LH side
front pillar. Bind the hoses together with hose
clips 7.
Make sure, that the hoses for condensing water
are not clamped.
--- Connect hoses to the expansion valve (o---ring
42 and 41)
--- To avoid water condensing, wrap round evapor -
ator outlet pipe and round the expansion valve
insulating mass 48 so that metal parts are
entirely covered by the mass.
Seal also hose lead---in points on the
housing
with the insulating mass.
Leave a small piece of insulating mass left, which
can be fitted later when reassembling the hous-
ing
--- Remove adhesive tape of the temperature
switch at the switch fitting point (on rear side)
and fit the sw itch. Pass the capillar tube carefully
towards the evaporator.
Pushthecapillartubebetweentheevaporator
fins to the depth of 90±10 mm according to the
picture (the tube must not touch the evaporator
pipes). Lock the tube by bending upper edge of
the fins against the tube.
Bend carefully the tube to the angle of 90˚ (do
not damage the tube). Coil round the excess
length of the tube and place it outside the hous-
ing
--- G lu e s e a l 46 on the evaporator. The seal is
placed partly on the part 67 (see picture 8).
Check that the evaporator is tight against the
housing halves.
