1181
89.2
Model
No Page
AIR CONDITIONING, FIT TING INSTRUCTION
(P T 94 --- cabin)
30.07.1999
11(28)
28.06.1999
6000---8750
6250Hi---8950Hi
--- Fa s t en la mp 53 (1 pcs) and the lamp bracket
32571100 with rubber seal 32570900 onto the
support plate (free hole on the plate).
--- Fit the wiring loom 52. Connector X15 (3 pins)
should be connected to the corresponding con-
nector in the roof wire loom. Connect wires no
77 (brown) equipped with branch connectors
and a white earth wire to the exsisting panel
illumination.
Connect wire loom 52 wire no 31 (blue) to the
temperature switch S8 (”in”). Find wire no 93
(black) in the roof wire loom and connect it to the
other pin (”out”) of the temperature switch
Connect the wire loom wire no 77 (brown) and
the white earth wire to the lamp 53.
--- Before fitting the housing cover, check that the
evaporator upper side is flush with the heater
radiator upper side.
--- Reassemle the tractor.
