120.06.1994 6000---8400 39
DPS--- EXTRA BUTTONS, FITTING
(3)
--- Delta Powershift--extra buttons 32948400...
(Suit only on tractors which have bush buttons for
DPS control).
--- These extra buttons can be fitted e.g. in the
reverse shuttle lever. This improves tractor control
specially when doing loading work.
--- Delta Powershift--extra buttons on
implement 32948500......................
(Suit only on tractors which have bush buttons for
DPS control).
--- With these control buttons the DPS ratio can be
changed on the implement.
--- FITTING (extra buttons, 32948400, e.g. into the
reverse shuttle lever):
--- Remove the reverse shuttle lever knob. Bend the
floor mar aside at the levers and detach the linings
in the lever lower part.
--- Fit the wiring loom 15 push buttons 17 onto the
frame 18 (order: the red wire is rearmost, the con-
nectors one on the other) and fit them into the knob
19. Pass the wiring loom through the reverse
shuttle lever. Fasten the knob, be careful not to
damage the wires).
--- Find the connector ”X23” in the lower part of the
levers and pull off the connector one half.
Connect the wiring loom 15 lower end connectors
to the connector half (order: see picture) and con-
nect the connector.
--- FITTING (extra buttons on implement),
32948500):
--- If the socket bracket in the rear of the tractor has
only one part, it should be changed to bracket 23.
The trailer socket is moved to the middle part of a
new bracket (do not disconnect the wires).
--- M a k e t h r e e w i r e s ( 1 , 5 m m
2
, lengths 2 m ), colour of
which should be blue, red and yellow).
Connect connectors 27 to one end of the wires and
connect them to the cab wiring loom connector
”X23” in the lower part of the levers (or to extra wir-
ing loom connector ”S23: ”, if this fitting is done at
the same time with the control unit), connections,
see picture.
