Model
No Page
312.08.1998 6000---8750 39.18
FIELDMASTER, fitting instruction
(10)
FITTING (other parts):
--- Remove the lever console side panel. Detach in
the upper part the AC power lift control panels (2
pcs).
Slacken the whole lever console fixing screws.
---MakethreadedholesM5(2pcs,drillø4,2)on
the rear face of the side pillar, and see picture A.
--- Open the side pillar linings in the front part of
the pillar and pass the display unit wire under
the linimgs into the lever console. Fasten the
diplay unit.
---Passthewireloom8 adapter 1 wires to the
lower part of the smaller control panel.
Connect the connectors to the adapter, see pic-
ture B.
Fasten the adapter to the rear side of the control
panel, and fit the panel.
--- P la ce t h e w i r e l oom 8 into the lever console.
Connect to the wire loom to the diplay unit con-
nector (“A16”)
---ConnectthewireloomsupplywireX55tothe
corresponding wire in the lever console (nr 17,
black).
--- Pass wires to the rear socket 7 along the cab
rear beam and push them out of the beam to the
rear of the tractor.
Fitanewsocketbracket6 in place of the earlier
one.
Connect the wires to the socket, see picture C.
Fasten the rear socket..
--- Tractors with Agrodata ---instrument:
Open the connector “X34” in the lever console
andconnectthewireloom8 correnspondent
connectors “X34” and “X34* “ between the
detached connectors. Wire loom connectors
“X39” and “X1E” are not used.
