Model
No Page
1(4)6000---8750 39.2
RAISED HEADLIGHTS, FITTING INSTRUCTION
09.04.1998
04.12.1995
Upraised headlights 32817000...............
Upraised headlights
( l e f t --- h a n d t r a f f i c ) 33423000
--- The raised headlights are needed when the tractor
has a front mounted implement (e.g. front loader)
which hampers visibility of the standard headlights.
The upper headlights are attached to the cab roof
front edge (in addition, the standard headlights are
fitted on the tractor). Driver can choose with a switch
which one of lights he wants to use. When the par-
king lights are switched on, also in---built parking
lights light in the upper headlights.
--- Fitting instruction:
--- Detach the working lights from their attachments in
the front edge of the roof. Remove the covering (1) and
the roof.
--- Open a little the inner roof so that the wiring loom (24)
can be passed into the roof side through the hole in the
side pillar and push the wire connector ends (E25, E23
and E24, E26) out of the roof front corners.
--- Connect the wiring loom wires nos 77 (2 pcs brown)
between the roof panel light (E16) supply wire (earlier
tractors: no 26 black wire) and the lamp base.
--- Connect the earth connector to the earth point /2.
--- Disconnect the working light connectors and change
places for working lights (the LH side light to the right
and the RH side light to the left).
--- Check all connections and fit the roof.
--- Fasten the support (2) to the fastening lugs.
--- Carefully clean the upper corners of the windscreen.
The stickers’ (15) round corners should be turned
downwards towards the driver’s seat. Mark the places
for the stickers: The visible edges of the stickers
should be about 10 mm outer than the corresponding
edges of the covering (1). Fasten the stickers onto the
windscreen.
--- Mark places for new fixing holes (6 pcs) on the roof
and use the covering (1) as a pattern. Drill ø4 mm
holes. Seal the earlier holes with e.g. silicone based
sealant.
--- Fasten the number plate back plate to the covering (1)
in the reverse direction so that it does not stand in the
working light way.
--- Fasten the covering (1) into place. There are rubber
washers (28) between the covering and the outer roof.
--- Assemble the headlights (parts 18, 20, 21 and 22, 26)
and fasten them onto the frames (11), see picture.
Connect the wiring loom to the bulbs and fasten the
assembled frames onto the covering
--- Fa s t e n t h e w o r k in g l i g h t s ( T OP --- ma r k in g u pw a r ds ) .
