582
Model
No Page
2(4)6000---8750 39.2
RAISED HEADLIGHTS, FITTING INSTRUCTION
09.04.1998
04.12.1995
--- Draw the wiring loom in cab inside the side pillar
linings and under the mudquard linings and further
in the cable channel under the floor mat into the
steering wheel console.
---Seek the connector X3 of the fuse box. If one wire
(black, no 52) is fitted in the connector pole 1,
modifications are unnecessary (the modifications
have been done from the cab no 3645--->). If two
wires are fitted in the pole 1, the following pro-
cedures must be done:
Cut off the thicker wire (1,5 mm
2
) beside the connector.
Procure about 0,5 m wire of the same thickness and con-
nect it to th e other end of the cut wire with connector SA
1553. Squeeze the plastic covering round the connector
by wa rmi ng it.
Tapethewireontothesideofthewiringloombehindthe
steering wheel column and draw it to the RH side of the
fusebox.
Disconnect wire no 53 black from the fusebox connector
X7 pole no 7. Use a small screwdriver to release the con-
nector locking claws. Remove the earlier connector from
the wire and connect this wire + the wire which was done
to the new connector SA 1776. Connect the connector
back to the connector X4 pole no 7.
--- Connect the wiring loom (24) between the connec-
tor X4 (see picture).
--- Fit the switch (25) and connect it to the wiring loom
(”S33”).
--- Check the function of the raised headlights. Adjust
thelights(seepicture).
1 32817000 Yläajovalot Över färdljus Upper head lights Obere Scheinwerfer
1 33423000 Yläajovalot Över färdljus Upper head lights Obere Scheinwerfer For Left--- hand traffic
1 1 32814200 .Suojus Skydd Shield Schutz
2 1 32816400 .Tuki Stöd Support Stütze
3 6 JD0408 .Aluslaatta Bricka Washer Scheibe
4 4 HA6323 .Ruuvi Skruv Screw Schraube
5 2 625510 .Aluslaatta Bricka Washer Scheibe
6 4 JB1108 .Mutteri Mutter Nut Mutter
7 4 31990000 .Lukituslevy Låsbricka Lock washer Sicherungsscheibe
8 4 31990500 .Kitkalevy Friktionplatta Friction plate Reibungsplatte
9 2 32816500 .Kiinnitin Fästdon Fastener Halter
10 4 JB8904 .Mutteri Mutter Nut Mutter
11 2 32816300 .Kehys Ram Frame Rahmen
12 8 JC9002 .Mutteri Mutter Nut Mutter
13 8 JD0405 .Aluslaatta Bricka Washer Scheibe
14 8 HN6804 .Ruuvi Skruv Screw Schraube
15 1 32817100 .Tarra Dekal Sticker Aufkleber assy
16 2 625510 .Aluslaatta Bricka Washer Scheibe
17 2 HA6323 .Ruuvi Skruv Screw Schraube
18 2 31547310 .Ajovalaisin Strålkastare Head light Scheinwerfer For Right---hand traffic
2 31590100 .Ajovalaisin Strålkastare Head light Scheinwerfer For Left---hand traffic
18A 2 32745300 ..Tiiviste Tätning Gasket Dichtung
19 6 32547600 ..Ruuvi Skruv Screw Schraube
20 2 SH2663 ..Lamppu Lampa Bulb Lampe
21 2 601610 ..Suojus Skydd Shield Schutz
22 2 32571100 ..Lampunpidin Lampfattning Bulb socket Lampenfuß
23 6 601640 .Jousi Fjäder Spring Feder
24 1 32816800 .Johdinsarja Ledningssats Wiring set Verkabelung
25 1 31877500 .Keinukytkin Vippströmbrytare Switch Schaukelschalter
1 32816900 .Linssi Lins Lens Linse
1 30944600 .Lampunpidin Lampfattning Bulb socket Lampenfuß + lamppu /+ bulb
