Model
Code Page
FITTING INSTRUCTION 26.07.1999 6000---8750
39.20
1(8)
AGRODATA--- INSTRUMENT PANEL
06.08.1997
Agrodata instrument panel A 33039000......
FITTING THE SENSORS:
--- Models 6000---8400 (these tractors don’t have
ACD--- electrohydraulic lift as standard):
Gearbox speed sensor B6 is fitted to the 4WD
drive shaft front end (gearbox).
Ifthesensorlocationonthe4WDclutchhousing
is desired, the tractor has to be splitted at the
gearbox.
Tractors 8450---8750: the sensor B6 (location on
the 4WD housing) and the harness 7 are
installed.
--- Sensor B6: remove the propeller shaft. Remove
the front shaft nut (do not touch the other one),
and fasten the support under the 4WD flange
screws.
--- Sensor B7: Remove the plug and clean the
threads. Find with a dial gauge the shortest dis-
tance between the sensor and the impulse disc
through the sensor hole.
--- B6, B7: Apply Loctite 572 onto the sensor
threads and turn it against the gear wheel /
impulse disc and then unscrew it 1/4 of a turn
(B7: do not screw too hard because the disc
can spring).
--- B6, B7: Lock the sensor with the nut and con-
nect wire harness 7.
--- B6, B7: Connect the wires to the sensor and
protect with grease UC1913 (vaseline spray
HHS 2000, Würth).
---B6,B7:Foldthewireonthesensorandfastenit
with a plastic cable tie. Fasten the wire to the
lock washer .
--- Temperature sensor B3: remove the plug and fit
the sensor (+ o---ring) instead. Connect the
wires to the sensor and protect with grease
UC1913.
--- Fa s t e n r e m o v e d p a r t s .
FITTING THE PARTS IN THE CAB:
--- Disconnect the battery earth lead. Remove the
instrument panel. Remove the lever console side
panel.
--- Connect the wires to the new instrument panel.
Connect the connector ”X25” to the wiring har-
ness 2. Fit the new instrument panel.
---Drawthewireloom2 together with other cables
along the floor into the lower end of the lever
housing and furthermore at the rear part of the
cab into the side console Bind the cable together
with the other cables.
