WAGNER TITANUS User Manual

TITANUS MICRO·SENS
®
Installation
MS_A_05-en-e Data: 01/09 5 – 35
5.13.1.10 Fire Alarm threshold after ROOM·IDENT
It can be useful for certain applications to activate the alarm after the lo-
calisation of the fire has completed. By using the diagnostic tool for
TITANUS MICRO·SENS
®
it is possible to enable or disable the function
“Fire alarm after ROOM IDENT ». Please note, that the function «ROOM
IDENT» has to be enabled as well when using this option. Otherwise lo-
calisation will not be performed.
Fire alarm after
ROOM·IDENT
Fire alarm after
ROOM·IDENT
Standard
Detection unit
DM-TM-10 off – on
off
Detection unit
DM-TM-50 off – on
off
“Fire alarm after ROOM IDENT « is disabled by default.
5.13.1.11 Setting the ventilator voltage
The standard setting for the ventilator voltage is 9 V. In critical applica-
tions the ventilator voltage can be set higher by using the TITANUS
MICRO·SENS
®
diagnostic tool, to raise the transport speed in the pipe
system and thus guarantee faster detection where there are longer pipe
runs.
With a ventilator voltage of 9 V to 10.4 V the maximum pipe lengths are
reduced to 30 m for the I-pipe and 40 m for the U and Double U-pipe
designs. From a ventilator voltage of 10.5 V upwards, the maximum pipe
length is given.
Ventilator voltage Ventilator voltage
Standard
Settings
stages
Detection unit
DM-TM-10 9 V – 13,5 V
9 V 0,1 V
Detection unit
DM-TM-50 9 V – 13,5 V
9 V 0,1 V
If the TITANUS MICRO·SENS
®
ventilator voltage is changed, the device
automatically carries out air flow initialisation.
ATTENTION

WAGNER TITANUS Specifications

General

Power Supply	24 V DC
Operating Temperature	-20°C to +60°C
Alarm Output	Relay contacts
Certification	VdS, EN 54
Humidity Range	10% to 95% (non-condensing)
