Pipe Design TITANUS MICRO·SENS
®
4 – 12 Data: 01/09 MS_A_04-en-e
4.2.2 Pipe accessories
Air filters
Type Application Examples
LF-AD
Coarse filter for separating
particles > approx. 15 µm
Dust, insects, fibres, hair,
cinders, pollen
LF-AD-1
Filter for separating particles
> approx. 10 µm
As above. Additionally:
Colour pigments and fine
dust
LF-AD-2
Fine filter for separating parti-
cles > approx. 5 µm
As above. Additionally:
Fine dust in low concen-
trations
SF-400
Fine filter for separating parti-
cles > approx. 1 µm
As above. Additionally:
Fine dust in high concen-
trations
SF-650
Fine filter for separating parti-
cles > approx. 1 µm
As above, but with in-
creased filter lifetime
Steam trap
Type Application
KA-DN-25
Condensation separator for applications with condensation mois-
ture in the pipe
Sound suppressor
Type Application
SD-1
Sound suppressor for areas sensitive to noise
Stop valve
Type Application
AVK-PV
Stop valve for VSK cleaning air nozzle
AVK-PV-F
Stop valve for VSK cleaning air nozzle for use in freezer areas
